Battery 36V15A
Color White,Black
Functional Features
Sensor PS.SW03-01
Motor 36V350W-UART
Functional Features
Sensor PS.SW03-01
Motor 36V350W-UART
| No. | Name | Model | Size | Unit | Qty |
| 1 | Aluminum alloy folding frame | Fish scale welding + film | set | 1 | |
| 2 | handlebar seat | SM-A92-8 | black7°Φ28.6 | pc | 1 |
| 3 | handlebar | SM-M-120 | length700 | pc | 1 |
| 4 | Seatpost | SM-2200 | Φ30.9
length320 |
pc | 1 |
| 5 | Front fork | D6 | 27.5 Iron straight pipe 214L mechanical lock | pc | 1 |
| 6 | left front disc brake | HD-M200F | all black hydraulic disc brake F 180MMdisc tubing length800MM Pole Mount with Pole Mount TEBOKA logo | pc | 1 |
| 7 | right rear disc brake | HE-M200R | all black hydraulic disc brake R 180MMdisc tubing length1500MM Split quick-connect column with installation TEBOKA logo | pc | 1 |
| 8 | down tube | IR-7 | xiniu7# | pc | 1 |
| 9 | gear shifter | ASLM3157RC | Shimano | pc | 1 |
| 10 | rear derailleur | ARDTY300D | Shimano | pc | 1 |
| 11 | Threaded flywheel | AMFTZ5007428 | Shimano | pc | 1 |
| 12 | Kenda inner and outer tires | 27.5*2.10 | 27.5*2.10 K1047 BK/CH 30TPI+AV package | set | 1 |
| 13 | Nylon lining | 27.5 | 27.5*20 Red Nylon lining single bag | pcs | 2 |
| 14 | chain | #Z7/GY/BR | KMC 120 Sections | pc | 1 |
| 15 | Sunflower screw set | GH-190 | 28.6*44-56*30 H:8.5 with 1-1/8 black without standard | pc | 1 |
| 16 | pedal | M-504 | black（Aluminum alloy） | pc | 1 |
| 17 | Quick Release Seatpost Clamp | KC88Q | 34.9mm black no mark | pc | 1 |
| 18 | Front fork top ring | D01L | 28.6*Φ34 H10mm black | pc | 5 |
| 19 | frame print | pc | 1 | ||
| 20 | stick | pc | 1 | ||
| 21 | single support | white mark | pc | 1 | |
| 22 | horn | pc | 1 | ||
| 23 | headlight | HD-110F | pc | 1 | |
| 24 | seat tube reflector | CHP-GH-723 | HT30.4 red | pc | 1 |
| 25 | rim reflector | DHP-787K | yellow | set | 1 |
| 26 | front、reartire | pc | 1 | ||
| 28 | JT2354 | with logo mark+SHENYANG | pc | 1 | |
| 29 | Grip | J869 | set | 1 | |
| 30 | Mid motor | M01 | 36V350W-UART | pc | 1 |
| 31 | hanger | set | 1 | ||
| 32 | Meter | CA01-1-01 | set | 1 | |
| 33 | Sebsor | PS.SW03-01 | set | 1 | |
| 34 | handle | TK-TR03-01-300mm | set | 1 | |
| 35 | power cable | A2.3-01-270mm | pc | 1 | |
| 36 | headlight wire | A0.2-2-01-1200mm | pc | 1 | |
| 37 | Integrated line one for two | JC.C02-1-01-1200mm | pc | 1 | |
| 38 | chainring assembly | 38T | set | 1 | |
| 39 | crank | 170mm | set | 1 | |
| 40 | carton | 1480mm*250mm*760mm | pc | 1 | |
| 41 | Standard Parts | set | 1 | ||
| 42 | charger | pc | 1 | ||
| 43 | Battery | 36V15A | set | 1 | |
| 44 | Fitting | pc | 1 | ||
| 45 | Pack with accessories | pc | 1 | ||
| 46 | management fee | pc | 1 | ||
| 47 | shift line | pc | 1 |
